Air Conditioner Cooling Outdoor Telecom Cabinet Galvanized Steel Includes 19 Inch Rack
1. Cabinet Summary
The outdoor telecom cabinet refers to a cabinet made of galvanized steel, directly under the influence of the weather, and does not allow unauthorized operators to access. Base station equipment, power supply, battery, temperature control equipment, transmission equipment and other ancillary equipment can be installed in the cabinet, which can provide reliable mechanical and environmental protection for the normal operation of internal equipments.
2.Cabinet Advantage
2.1 Short construction period, less land occupation, broader application and lower construction cost
2.2 High integration, compact structure, easy installation and migration on later stage
2.3 High-performance cooling solution,include air conditioner and fan.
2.4 Anti-theft three-point outdoor cabinet lock
2.5 Professional outdoor anti-corrosion powder coating, strong weather resistance, waterproof & dustproof.
3. Cabinet Parameters
| Configuration | Item | Technical Parameter |
| Cabinet Body | Size | External Size W×D×H: 750×750mm×1750mm |
| Component | The whole cabinet includes three parts: the top cover, the cabinet body and the base. The installation method is floor mount. |
| Material | Galvanized steel, double wall with heat insulation. |
| Structure | - One front door , hidden zinc alloy hinge.
- Outdoor special steel lock, lock cylinder assembled with protective cover, lock body assembled with anti-theft three-point lock(support padlock).
- Door stopper is installed on the inside of the cabinet door.
- Grooved door with seal rubber strip, attached to the inner side of the door, waterproof and dustproof.
- Include 19“ rack
- Cable inlets at the bottom of cabinet.
- Grounding protection: copper bar.
|
| Surface Treatment | Deoil, acid pickling, phosphating, electrostatic spraying, high temperature solidification |
| Color | Anti-corrosion outdoor powder coating RAL7035 |
| Ingress Protection | IP55 |
| Working Temperature | -40°C～+85°C |
| Cooling Method | Air Conditioner | Cooling capacity: 1000W; Power Supply: DC48V; Installed on front door |
4.Cabinet Cooling System
The cabinet has one 1000W cooling capacity installed on the fornt door
5.Cabinet Detailes
5.1 Cabinet Material
The cabinet is made of galvanized steel, single plate, thickness of plate is 1.2mm, with 20mm PEF heat insulation. The cabinet is assembled type.
5.2 Cabinet Door
The cabinet door uses embedded structure.
The door opening angle is larger than 110°and the door limit device can limit the opening angle.
The cabinet door lock is theftproof three point lock, supporting padlock.
6.Cabinet Package
Wooden case package.
